TECHNICAL DATA SHEET
Codes Followed:
1. Steel Design: IS:800, IS:802, IS:875
2. Steel Material: MS Plates & Sections - IS:2062 Gr A/B/Br E250 (Yst 250MPa) and E350 (Yst 350MPa) MS Pipes and Tubes - IS:1161 & IS:4923 Yst 240MPa and Yst 310MPa
3. Hot Dip Galvanization: Average Thickness of Zinc Coating 610-gms/sqm. IS:4736 & IS:4759
4. Fasteners - Hot Dip Galvanized Grade 5.6 or 8.8 IS:12427; IS:2016; IS:3063
5. Welding - IS:816 and IS:16003
6. Fabrication Tolerances - IS:7215
Raw Material Source Qualification
1. Angle Sections: BIS Certified, SAIL Approved Re-Rolling Mills, PGCIL Certified Mills, RINL, JSPL, SAIL
2. Plates: SAIL, JSW
3. Pipe & Tubes: Jindal, TATA, Apollo
4. Zinc - Hindustan Zinc
5. Welding Electrodes & Wire: ADOR, D&H, L&T, Modi, Maruti
Quality
We have adopted a robust Manufacturing Quality Assurance Plan for Fabrication and Galvanizing. A copy can be viewed here.
